配電自動化饋線終端（FTU）
出口經濟版重合閘控制器-economic type controller
所屬分類：
產品簡介
This ROCKWELL economic type controller which is used for medium voltage overhead line monitoring and controlling, which can be equipped with pole mounted switchgear achieve of automatic monitoring, fault analysis and event records, and drive switch to isolate off line fault, recovery gird safety running.
It’s suitable for up to 35kV outdoor switchgear using, include: vacuum circuit breakers, oil circuit breakers and gas circuit breakers.
This type of product gathering with all the functions like:
line protection, controlling, measurement and monitoring of voltage and current signals.
It’s suitable for up to 35kV outdoor switchgear using, include: vacuum circuit breakers, oil circuit breakers and gas circuit breakers.
This type of product gathering with all the functions like:
line protection, controlling, measurement and monitoring of voltage and current signals.
| 出口經濟版重合閘控制器-economic type controller的概述 |
|
出口經濟版重合閘控制器是中壓架空線路電網的監控單元，與柱上開關配合實現線路狀態自動監控、故障分析、判斷記錄，具備驅動開關保護線路設備安全，切斷線路故障及自動恢復線路運行等功能。適用于35KV及以下戶外開關設備，包括真空斷路器，油斷路器及氣體斷路器。
出口經濟版重合閘控制器是集線路保護、控制、電壓電流信號測量、監視于一體的綜合自動化戶外測控裝置。
This ROCKWELL economic type controller which is used for medium voltage overhead line monitoring and controlling, which can be equipped with pole mounted switchgear achieve of automatic monitoring, fault analysis and event records, and drive switch to isolate off line fault, recovery gird safety running. It’s suitable for up to 35kV outdoor switchgear using, include: vacuum circuit breakers, oil circuit breakers and gas circuit breakers. This type of product gathering with all the functions like: line protection, controlling, measurement and monitoring of voltage and current signals. |
| 出口經濟版重合閘控制器-economic type controller的功能 |
|
1、具有速斷、限時速斷、定時限過流的三段式保護功能； 2、具有手合加速段保護功能，斷路器合于故障加速跳閘，并閉鎖合閘； 3、具有0~4次自動重合閘功能，滿足“分-t1-合分-t2-合分-t3-合分-t4-合分-閉鎖”工作特性，具有重合閘后加速功能，重合次數、延時可自由設定； 4、具有零序保護功能，能判斷小電流故障； 5、具有涌流抑制保護功能； 6、具有PT過壓分閘保護功能； 7、具有PT失壓分閘保護功能； （根據用戶需求添加） 8、具有得電合閘保護功能； 9、具有頻率保護功能； 10、具有預付費保護功能； （根據用戶需求添加） 11、具有儲能告警功能； 12、其它功能：事件記錄、實時時鐘、實時狀態查詢； 13、可選功能：SOG保護功能、雙PT功能、CT防開路功能、智能手機控制（藍牙）、GPRS無線通訊、手機短信（GSM）。 Detail Functions: 1、with Instantaneous over current protection, definite time over current protection and over current protection protection; 2、with Manual closed accelerating protection, the breaker will trip fast when it’s closed in fault, and it will trip and lockout close operation; 3、with 0 to 4 shots reclosing, “O-t1-CO-t2-CO-t3-CO-t4-CO-lockout”,with Reclose accelerating protection, shots setting, delay time setting; 4、with zero sequence over current protection, E/F, SEF; 5、with cold load protection ; 6、with over-voltage protection ; 7、with under-voltage protection ;（optional） 8、with electricity-running close protection ; 9、with frequency protection ; 10、with relay for pre-payment meter input;（optional/definable） 11、with motor emerging failure alarm; 12、Event record, Real-time sync, Real time checking, 13、Optional functions: Sectionalizing SOG protection, Double-PT, protection for CT circuit, intelligent phone control/blue booth, GPRS communication, Mobile-phone message/GSM. |
